REMOVING THE COVERS
Bottom cover plate
Open the five M5 nuts and remove the nuts, washers and springs. Remove the cover.
Bottom cover plate
Figure 111
Technical Manual
Chapter E - C-ARM AND IMAGING ARM
Planmeca ProMax E-85
Nut
Washer
Spring
Washer
