Planmeca ProMax Technical Manual page 369

ProMax RTC (121-10-04), location of indicators
ProMax MCM (121-10-09), location of indicators
D1
ProMax CPH (121-10-18), location of indicators
R efer ence N am e C olor / N or m al idle status
D 1 +5V Green / normally on
T P 1 +5V +4.75 ... +5.25 Vdc
D5
R efer ence N am e C olor / N or m al idle status
D 1 Enable Yellow / lit only when enabled
D 5 PWR Green / normally on
R efer ence N am e
J1
Ref. Sensor 2
J2 Motor + ref. sensor 1
J3 Up/Dwn switch
J4 Patient Rotation
J5 Autoprint
J6 Casette switches
J7 Ceph Arm I/O
AEC ???????
J8
J9 -
J10 AEC
J11 Laser
J12 Laser
J13 Laser
R T C - IN D IC A T O R S & T E S T -P O IN T S
D etails
Indicates that the RTC-PCB is connected and receives power
MC M - IN D IC A T O R S
D etails
Indicates that module is enabled and the motor can receive power
Indicates that module reveices power from host PCB
C O N N E C T O R S & JU MP E R S & S W IT C H E S
N or m al usage D etails
only in digital ceph ceph scanning motor limit sensor
only in digital ceph ceph scanning motor limit sensor
always
always patient rotation limit switches
only with Autoprint Autoprint marking head
only in panceph casette position
only in CA-ceph units interface to ceph arm switches
only in panceph (optional)
-
only in panceph (optional)
always patient position laser
no connection
always patient laser potentiometer
