REPLACING THE COLUMN MOTOR
Chapter G - COLUMN
Open the accessory cabinet door or remove the lower front panel. Unscrew the two M4x6 DIN
7984 screws of the motor cover and remove the cover.
Motor cover
Figure 38
Detach the emergency stop switch by unscrewing the two M4x6 DIN 7984 attachment
screws.
Emergency stop switch
Figure 39
Technical Manual
Planmeca ProMax G-19
