DETACHING AND ATTACHING THE SENSOR HEAD
Turn the locking knob over the fastening mechanism. This will secure the sensor head in posi-
tion.
Figure 104
Push in the button of the cephalostat electrical connector behind the sensor head quick con-
nector mechanism. This will secure the sensor head in position and make the electrical
connection between the sensor head and cephalostat.
Button of the cephalostat
electrical connector
Figure 105
Technical manual
Locking knob
