Planmeca ProMax Technical Manual page 375

ProMax ETH (121-10-25), location of indicators
TP1 TP2 TP3
TP6
TP7 TP8 TP9
D3 D4
Reference Name
D1
LINK
D2
RX/TX
D3
+5V
D4
+3.3V
Reference Name
TP1
RESET
TP2
CS_EXT1
TP3
WAIT
TP4
-
TP5
-
TP6
IRQ_EXT1
TP7
+5V
TP8
+3.3.V
TP9 GND
ProMax CCM (121-10-12), location of indicators
D2
D3
D1 D2
INDICATORS
Color / Normal status
Green / always
Green / always when Ethernet Connected-
Green / always
Green / always
TESTPOINTS
Voltage at normal operation
-
-
-
-
-
-
+5V
+3.3.V
-
Reference Name
Reference Name
D10
D5,D6,D7,D8,D9,D12
TP4
TP5
Details
-
-
-
Details
-
-
-
-
-
-
-
-
-
Color / Normal status
D2
Solenoid status Green / used in ceph, mag., tomo Secondary collimator solenoid
D3
Solenoid status Green / used in ceph
D5
BLHOME Yellow
D6
SECCOLCLO Yellow
D7
CASINPLACE Yellow
D8
CASPHB Yellow
D9
CASPHA Yellow
D10
ENABLE Red
D11
CASINPLACE Green
D12
+5V Yellow
CONNECTORS & JUMPERS & SWITCHES
Normal usage
J1
Sensor used in ceph, mag., tomo
J2
Solenoid used in ceph, mag., tomo
J3
AEC Interface used in AEC mode, optional
J4
Solenoid used in ceph
J5
CCM interface always
J6
Autoprint PCB used in AEC mode, optional
INDICATORS
Details
Primary protective shielding solenoid
BLHOME
SECCOLCLO
CASINPLACE
CASPHB
CASPHA
?
Casette in place detector
?
Details
Secondary collimator closed position
Secondary collimator solenoid
Primary protective shielding solenoid
-
Autoprint Interface
