ST STM32L4 5 Series Reference Manual page 1483

RM0351
43.5.5 Slot register (SAI_ASLOTR / SAI_BSLOTR)
Address offset: Block A: 0x010
Address offset: Block B: 0x030
Reset value: 0x0000 0000
Note: This register has no meaning in AC'97 and SPDIF audio protocol
31 30 29
rw rw rw
15 14 13
Res. Res. Res. Res.
Bits 31:16 SLOTEN[15:0]: Slot enable.
These bits are set and cleared by software.
Each SLOTEN bit corresponds to a slot position from 0 to 15 (maximum 16 slots).
0: Inactive slot.
1: Active slot.
The slot must be enabled when the audio block is disabled.
They are ignored in AC'97 or SPDIF mode.
Bits 15:12 Reserved, must be kept at reset value
Bits 11:8 NBSLOT[3:0]: Number of slots in an audio frame.
These bits are set and cleared by software.
The value set in this bitfield represents the number of slots + 1 in the audio frame (including the
number of inactive slots). The maximum number of slots is 16.
The number of slots should be even if FSDEF bit in the SAI_xFRCR register is set.
The number of slots must be configured when the audio block is disabled.
They are ignored in AC'97 or SPDIF mode.
28 27 26 25
rw rw rw rw
12 11 10 9
NBSLOT[3:0]
rw rw rw
DocID024597 Rev 5
24 23 22 21
SLOTEN[15:0]
rw rw rw rw
8 7 6 5
SLOTSZ[1:0] Res.
rw rw rw
Serial audio interface (SAI)
20 19 18 17
rw rw rw rw
4 3 2 1
FBOFF[4:0]
rw rw rw rw
16
rw
0
rw
1483/1830
1490
