States - Danfoss VLT HVAC Basic Drive Programming Manual

Parameters
13-44 Logic Rule Boolean 3
Array [6]
Option:
[35] Digital input DI27
[36] Digital input DI29
3 3
[39] Start command
[40] Drive stopped
[42] Auto reset trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken belt
[100] Firemode

3.9.6 13-5* States

13-51 SL Controller Event
Array [20]
Option:
[0] False
[1] True
*
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
56
VLT HVAC Basic Drive Programming Guide
Function:
Function:
Select the boolean input (TRUE or
FALSE) to define the Smart Logic
Controller event.
See 13-02 Stop Event for further
descriptions of choices and their
functions.
MG.18.B1.02 - VLT
13-51 SL Controller Event
Array [20]
Option:
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto reset trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken belt
13-52 SL Controller Action
Array [20]
Option:
[0] Disabled
*
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
®
is a registered Danfoss trademark
Function:
Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
13-51 SL Controller Event) is evaluated
as true. The following actions are
available for selection:
Changes the active set-up (0-10 Active
Set-up) to '1'.
Changes the active set-up (0-10 Active
Set-up) to '2'.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active
preset reference is changed, it will
merge with other preset reference
commands coming from either the
digital inputs or via a fieldbus.
