5 | Product Overview

5.10 Specifications

5.10.1 Physical Operating Requirements

44 / 319
2-module chassis
Maximum weight
Dimensions (L x W x H)
Installation (Overvoltage)
Power supply input
Power supply output
Operating temperature
Storage temperature
Relative humidity
Altitude
Pollution degree
Vibration
4-module chassis
Maximum weight
Dimensions (L x W x H)
Installation (Overvoltage)
Power supply input
Power supply output
Fuse
Operating temperature
Storage temperature
Relative humidity
Altitude
Pollution degree
WARNING
Replace only with fuse of the same type and rating to avoid fire and personal
injury.
Specification
6.2 kg (13.6 lb.)
46.2 x 19.6 x 25.4 cm (18.2 x 7.7 x 10 in.)
Category II per IEC 60664
100 to 240 V (ac), 50 to 60 Hz, 5A
24 V (dc), 10.83 A, 260 Watts maximum
0°C to 50°C (32°F to 122°F) ambient
-20°C to 60°C (-4°F to 140°F) ambient
5 to 95% (non-condensing)
2,000 m (6,562 ft.)
2 per EN 61010
MIL-STD-810F-514.5C, Highway Truck Vibration
Specification
15.4 kg (33.8 lb.)
47.5 x 43.2 x 27.1cm (18.7 x 17 x 10.7 in.)
Category II per IEC 60664
100 to 240 V (ac), 50 to 60 Hz, 7A
24 V (dc), 42 A, 1008 Watts maximum
250 V (ac), 10 A
0°C to 50°C (32°F to 122°F) ambient
-20°C to 60°C (-4°F to 140°F) ambient
5 to 95% (non-condensing)
2,000 m (6,562 ft.)
2 per EN 61010
