Create A Custom Bakeout Method - Inficon Micro GC Fusion 2-Module Operating Manual

INFICON

10.2.2 Create a Custom Bakeout Method

Column Type Temperature Programmed
(Max. °C)
Rt-Molsieve 250
Rt-U-Bond 120
Rt-Q-Bond 250
Rt-Alumina 200
Rtx-1 or Rxi-1ms 250
074-594-P1H Micro GC Fusion Operating Manual
Alternately, a bakeout method can be created and customized. A bakeout method can
be created by modifying the final temperature and/or hold time of an existing
temperature programmed or isothermal analytical method.
CAUTION
Always observe the column phase and module temperature limitations in the
table.
Duration (Max.
Minutes)
5
5
5
5
5
To create a bakeout method:
1
Click the icon.
2 Click the Methods/Sequences button.
3
In the Methods/Sequences window, select the desired method for editing.
4
Click the icon to copy the method.
5
Type Bakeout in the Enter new name box.
Isothermal Temperature
(Max. °C)
225
120
225
180
225
Routine Operation | 10
Duration (Max.
Minutes)
120
120
120
120
120
253 / 319
