6.2 Instrument Hardware Setup

6.2.1 Unpacking the Instrument

6.2.2 Ship Kit Contents

6.2.2.1 Common to Every Instrument

6.2.2.2 Configuration Dependent Parts

Sample inlet parts
Quick connect
Carrier gas inlet parts
Power supply
074-594-P1H Micro GC Fusion Operating Manual
Verify the contents of the order, including accessories, consumables and checkout
gases using the included packing list. The contents of the ship kit should also be
verified.
A Micro GC Fusion ship kit is included with each instrument. Some items are common
to all configurations and some items are instrument configuration dependent.
PN Description
952-437-P1 1/8 in. outer diameter,0.065 in. inner diameter
copper,10 ft., cleaned
952-417-G1 Nut and ferrule set 0.062 and 0.125
600-1190-P4 Ethernet communication cable 4.3 m
074-666-P1 Micro GC Fusion quick start guide
PN Description
952-423-P1 Filter and holder assembly 0.062
FRL-1269 Dual end ferrule for 1/16 in. inlet
952-418-G1 Gas sample tube 0.062 with nuts
059-0718 Frit disk, 10 μm, 0.062 OD, 5 pack,
RoHS
PN Description
059-0329 Quick connect SS-QM2-D-200
PN Description
059-0701 Filter, inline, 1/8-tube, 2 µm pore
PN Description
952-435-P1S Power supply 24 V (dc)
600-1546-P1S Cable assembly 24 V (dc)
Quantity
Inlet Quantity
Front
Front
Front
Front
Inlet Quantity
Quick connect
Number of Carriers
1-4
Chassis Quantity
2-module only 1 pc
2-module only 1 pc
Installation | 6
1 pc
1 pc
1 pc
1 pc
1 pc
2 pc
1 pc
1 pc
1 pc
Quantity
1-4 pc
