8 | Front Panel Operation
150 / 319
The following table illustrates the icons on each corner of the front panel display.
Icon Name Enabled on Front
Panel Display (Y/N)
Home
Gear
Information
Wrench
The figure and table below illustrate the labels and buttons on the front panel display.
3
Item Name
1 Method or Sequence Preset Buttons
2 RUN Button
3 Method or Sequence Loaded
4 Notifications Label
5 Hostname and IP Address Label
Function
Y Return to the main operation screen
Y Access stored report and
chromatogram
N Access to Micro GC Fusion Operating
Manual
Y Access to system status
5
1
2
Function
Provides access to stored methods
or sequences
Initiates a sample run based on the
loaded method or sequence
Displays the loaded method or
sequence
Displays system status or error
messages
Displays the instrument network
hostname and IP Address
