Inficon Micro GC Fusion 2-Module Operating Manual page 279

INFICON
074-594-P1H Micro GC Fusion Operating Manual
CAUTION
Overtightening the sample line nut may damage the thread on the GC module.
9
Repeat steps 2 to 8 if replacing both modules.
10
When all the GC modules are replaced, replace the rear foam.
11 Replace the side foam. Ensure the dovetail joint is oriented as shown.
12
Replace the top foam by grasping one front corner and the opposite back corner,
and pressing straight down.
13
Replace the two small air filters on the top at the front of the unit.
Routine Operation | 10
279 / 319
