6.13.1.3 10-Port SD Valco Stream Selector Accessory

074-594-P1H Micro GC Fusion Operating Manual
When sample or calibration gas is abundant and sample composition changes quickly
over time, the flow-through (SF) Valco stream selector is the desired choice.
The pre-assembled accessories have 1/16 in. sample line filters installed at each inlet
port. These sample lines are leak checked at the factory and are labeled to provide
clear identification. For instance, the sample port #1 is labeled as 1 IN and sample
port #2 is labeled as 2 IN. The outlet sample line going into the GC is labeled as OUT
TO GC.
Description
10-port SD Valco stream
selector
Power supply
Quantity Photo
1
1
