6.1 Site Preparation

6.1.1 List of Required Tools

56 / 319
Proper site preparation prior to installing Micro GC Fusion is critical. Contact INFICON
(www.inficon.com) with any questions regarding site preparation.
Bullet points (.) identify hardware that must be available and actions that must
be addressed when installing Micro GC Fusion.
The following tools are user supplied:
• 1 1/8 in. wrench recommended, or adjustable large wrench (for attaching regulator
to gas tank)
• Teflon® tape for regulator connections
• 1/16 in. tubing and fittings for connection to the sample inlet
• Philips #2 screwdriver (for rack mounting)
The following tools and parts are included in the optional Install Kit (PN 952-021-G1)
to facilitate installation. If the optional install kit was not purchased, the tools and parts
below must be provided by the user upon installation.
PN Description
059-0442 Ball valve, 2-way. 0.125-tube brass RoHS
059-0449 Union tee, 0.125-Tube, 0.437 nut brass RoHS
059-0554 Nut, 0.125-Tube, 0.437 Hex, 0.47 Lg Brass RoHS
059-0714 Ferrule set, 0.125-Tube 10 pack brass RoHS
069-0115 Copper tubing, 0.128 OD, 0.065 ID
070-1999 Hex driver, 2.5 mm ball point L-handle SS RoHS
070-2000 Tubing cutter, 0.125 to 0.625 OD tubes, RoHS
070-2002 Wrench combination, 0.312 steel RoHS
070-2003 Wrench combination, 0.437 steel RoHS
070-2004 Wrench combination, 0.562 steel RoHS
074-594-P1H Micro GC Fusion Operating Man-
INFICON
Quantity
2 pc
1 pc
4 pc
4 pc
1 pc
1 pc
1 pc
2 pc
2 pc
1 pc
ual
