9 | Software Operation

9.12.1.1 Position Assignments

9.12.1.2 Purge Position

238 / 319
4
The valve Settings window will display. Ensure that the Enabled option is
selected if the Valco stream selector is connected with the Micro GC Fusion.
Individual valve positions can be assigned with unique names.
1
Click on the desired position.
2
Type a name in the field. Unnamed positions will retain their original position
number.
To assign a purge position:
1
Select the Returns to Purge Position option.
2
Click the icon next to the desired purge position. The icon will turn white to
indicate that the position has been selected.
