INFICON
5.10.2 Sample Inlet
5.10.3 Integrated Sample Conditioner
5.10.4 Gas Liquid Separator
5.10.5 Pressure Reducer and Gas Liquid Separator
5.10.6 Sample Injector
074-594-P1H Micro GC Fusion Operating Manual
Sample Inlet
Front inlet
Maximum sample pressure
Recommended sample pressure
Integrated Sample Conditioner
Front inlet
Maximum sample pressure
Minimum sample pressure
Gas Liquid Separator
Sample inlet
Maximum sample pressure
Pressure Reducer and Gas Liquid Separator
Sample inlet
Maximum sample pressure
Sample Injector
Variable volume
Variable large volume
Fixed volume
Backflush to vent
Specification
Heated, 30-140°C (86-284°F), 1/16 in.
Swagelok
172 kPa (25 psi)
Ambient to 69 kPa (10 psi)
Specification
Heated, 100°C (212°F), 1/8 in. quick
connect
6,895 kPa (1,000 psi)
34.5 kPa (5 psi) suggested for optimal
purging
Specification
1/16 in. Swagelok
172 kPa (25 psi)
Specification
Heated, 1 to 10 uL
Heated, 1 to 30 uL
Heated, 1.6 uL
Heated, 0.4 or 1 uL fixed, 7.1 uL maximum variable
Product Overview | 5
Specification
1/8 in. Swagelok
3,450 kPa (500 psi)
45 / 319
