9.10.6.2 Export as CSV
074-594-P1H Micro GC Fusion Operating Manual
1
Select the run(s).
2
Click the
icon.
3
Type the file name in the Name: field. This name is saved onto the computer.
4
From the Format: shortcut menu, select CSV.
5
From the Data: shortcut menu, select All or Compound Trend.
6
Click the
icon. The file(s) will download to the browser's default downloads
folder.
7
Open the file using Microsoft Excel or Notepad.
When exporting All data, the raw data is present in the file. This enables the
user to construct a chromatogram in Microsoft Excel.
When multiple runs are selected, Compound Trend is the only available
option. Compound Trend contains only concentration, area, and retention time
information and does not include the raw data.
Software Operation | 9
197 / 319
