Specifications - Inficon Micro GC Fusion Installation Sheet

Installation Sheet

Specifications

ESC sample inlet connection
Sample output temp to Micro GC Fusion
Maximum sample pressure
Minimum sample pressure
Sample output pressure to Micro GC Fusion 0-172 kPa (0-25 psi)
High pressure venting connector
Low pressure venting connector
Filter
Power input
Power output
Operating temperature
Storage temperature
Relative humidity
Altitude
Pollution degree
Installation (overvoltage)
Cleaning
NOTE: The Micro GC Fusion external sample conditioner is designed for indoor use only.
2 / 19
WARNING
Do not open the instrument case. There are no user-serviceable components within the instrument case.
Dangerous voltages may be present whenever power is present. Refer all maintenance to qualified personnel.
CAUTION
Do not use the product in a manner not specified by the manufacturer. If the product is used in a manner not
specified by the manufacturer, the protection provided by the equipment may be impaired.
CAUTION
Use caution when mounting the external sample conditioner to a fixed position. Ensure there is enough room
to disconnect the power cord when needed.
WARNING
When working with chemicals, follow PPE guidelines listed in chemical safety data sheets (SDS).
1/4 in. Swagelok® female quick connect
>50°C (122°F)
5516 kPa (800 psi)
14 kPa (2 psi)
1/8 in. Swagelok
1/16 in. Swagelok
7 µm
85 to 264 V (ac), 47 to 63 Hz
24 V (dc), 6.67A, 160 Watts maximum
0°C to 50°C (32°F to 122°F) ambient
-20°C to 60°C (-4°F to 140°F) ambient
5 to 95% (non-condensing)
2,000 m (6,562 ft.)
2 per EN 61010
Category II per IEC 60664
Use a mild, non-abrasive cleaner or detergent. Ensure the cleaner does not enter the unit.
074-732-P1A Micro GC Fusion External Sample
Conditioner Installation Sheet
