INVT Goodrive 35 Series Operation Manual page 166

Goodrive35 inverters
Function
code
HDO high-speed pulse
P06.16
Lower output limit of AO1 -300.0% – P06.19
P06.17
Corresponding AO1 output
P06.18
of lower limit
Upper output limit of AO1 P06.13 – 300.0%
P06.19
Corresponding AO1 output
P06.20
of upper limit
P06.21 AO1 output filter time
Lower output limit of AO2 -300.0% – P06.24
P06.22
Corresponding AO2 output 0.00 V – 10.00 V
P06.23
Name
2: Ramp reference frequency
3: Running rotation speed
4: Output current (relative to 2 times of the
rated current of the inverter)
5: Output current (relative to 2 times of the
rated current of the motor)
6: Output voltage
7: Output power
8: Set torque value
9: Output torque
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: High speed pulse HDI input value
14: MODBUS communication set value 1
output 15: MODBUS communication set value 2
16: PROFIBUS/CANopen communication set
value 1
17: PROFIBUS/CANopen communication set
value 2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20 – 21: Reserved
22: Torque current (100% corresponds to 10
V)
23: Pre-magnetizing current (100%
corresponds to 10 V)
24: Setting frequency (bipolar)
25: Ramp reference frequency (bipolar)
26: Operation speed (bipolar)
0.00 V – 10.00 V
0.00 V – 10.00 V
0.000 s – 10.000 s
Detailed instruction of parameters
159
Basic operation instruction
Default
value
0
0.0%
0.00 V
100.0%
10.00 V
0.000 s
0.0%
0.00 V
