INVT Goodrive 35 Series Operation Manual page 89

Goodrive35 inverters
Function
Name
code
stopping state
Frequency
P07.08
coefficient
Rotation speed
P07.09
coefficient
Linear speed
P07.10
coefficient
Rectifier bridge
P07.11 module
temperature
Converter module
P07.12
temperature
Software version 1.00 – 655.35
P07.13
Local
P07.14 accumulative
running time
MSB of power
P07.15
consumption
LSB of power
P07.16
consumption
P07.17 Reserved
Detailed instruction of parameters
BIT0: set frequency ( Hz on, frequency flickering
slowly)
BIT1: bus voltage ( V on)
BIT2: input terminals state
BIT3: output terminals state
BIT4: PID reference (% flickering)
BIT5: PID feedback value (% flickering)
BIT6: torque reference (% flickering)
BIT7: AI1 ( V on)
BIT8: AI2 ( V on)
BIT9: AI3 ( V on)
BIT10: HDI frequency
BIT11: PLC and the current stage in multi-step speed
BIT12: pulse counters
BIT13: length value
BIT14 – BIT15: reserved
0.01 – 10.00
Displayed frequency=running frequency* P07.08
0.1 – 999.9%
Mechanical rotation speed =120*displayed running
frequency×P07.09/motor pole pairs
0.1 – 999.9%
Linear speed= Mechanical rotation speed×P07.10
-20.0 – 120.0° C
-20.0 – 120.0° C
0 – 65535h
Display the power used by the inverter.
The power consumption of the inverter
=P07.15*1000+P07.16
Setting range of P07.15: 0 – 65535 kWh (*1000)
Setting range of P07.16: 0.0 – 999.9 kWh
Reserved
82
Function parameters
Default Mod
value ify
○
1.00
○
100.0%
○
1.0%
●
●
●
●
●
●
●
