INVT Goodrive 35 Series Operation Manual page 106

Goodrive35 inverters
Function
Name
code
Frequency-decrea
P11.01 sing at sudden
power loss
Frequency
P11.02 decreasing ratio at
sudden power loss
Overvoltage stall
P11.03
protection
Voltage protection
P11.04
of overvoltage stall
P11.05 Current limit
Detailed instruction of parameters
1: Input phase loss protection enable
LED tens:
0: Output phase loss protection disable
1: Output phase loss protection enable
Note: The default value is 0*10 for models below 2.2
kW
0: Enable
1: Disable
Setting range: 0.00 Hz/s – P00.03 (max frequency)
After the power loss of the grid, the bus voltage drops
to the sudden frequency-decreasing point, the
inverter begin to decrease the running frequency at
P11.02, to make the inverter generate power again.
The returning power can maintain the bus voltage to
ensure a rated running of the inverter until the
recovery of power.
Voltage degree
Frequency-decreasing
threshold
Note:
1. Adjust the parameter properly to avoid the
stopping caused by inverter protection during the
switching of the grid.
2. Prohibition of input phase loss protection can
enable this function.
0: Disable
1: Enable
120 – 150% (standard bus voltage) (380 V)
120 – 150% (standard bus voltage) ( 660 V)
The actual increasing ratio of motor speed is lower
99
Function parameters
380 V 660 V
460 V 800 V
Default Mod
value ify
○
0
○
10.00 Hz/s
○
0
136%
○
120%
◎
1
