INVT Goodrive 35 Series Operation Manual page 105

Goodrive35 inverters
Function
Name
code
P10.36 PLC restart
Multi-step time
P10.37
unit
P11 Group Protective parameters
Phase loss
P11.00
protection
Detailed instruction of parameters
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.35
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
After users select the corresponding ACC/DEC time,
the combining 16 binary bit can be changed into
hexadecimal bit, and then set the corresponding
function codes.
ACC/DEC time 1 is set by P00.11 and P00.12;
ACC/DEC time 2 is set by P08.00 and P08.01;
ACC/DEC time 3 is set by P08.02 and P08.03;
ACC/DEC time 4 is set by P08.04 and P08.05.
Setting range: 0x0000 – 0xFFFF
0: Restart from the first step; stop during running
(cause by the stop command, fault or power loss),
run from the first stage after restart.
1: Continue to run from the stop frequency; stop
during running (cause by stop command and fault),
the inverter will record the running time automatically,
enter into the stage after restart and keep the
remaining running at the setting frequency.
0: Seconds; the running time of all steps is counted
by second
1: Minutes; the running time of all steps is counted by
minute
0x00 – 0x11
LED ones:
0: Input phase loss protection disable
98
5 00 01 10
6 00 01 10
7 00 01 10
8 00 01 10
9 00 01 10
10 00 01 10
11 00 01 10
12 00 01 10
13 00 01 10
14 00 01 10
15 00 01 10
Function parameters
Default Mod
value
11
11
11
11
11
11
11
11
11
11
11
0
0
11
ify
◎
◎
○
