C.4.2 Flange Installation - INVT Goodrive 35 Series Operation Manual

Goodrive35 inverters
Model
1.5 kW – 2.2 kW
4 kW – 5.5 kW
7.5 kW – 11 kW
15 kW – 18.5 kW
22 kW – 30 kW
37 kW – 55 kW
75 kW – 110 kW
132 kW – 200 kW
220 kW – 315 kW

C.4.2 Flange installation

Wall installation of 380 V 220-315 kW inverters
Installation dimension (unit: mm)
W1 W2
126 115
146 131
170 151
230 210
255 237
270 130
325 200
500 180
680 230
Flange installation of 380 V 1.5-30 kW inverters
Appendix C Dimension drawings
H1 H2
193 175
263 243.5
331.5 303.5
342 311
407 384
555 540
680 661
870 850
960 926
250
D1 Installation hole
5
174.5
6
181
6
216
6
216
7
245
7
325
9.5
365
11
360
13
380
