D.6.2 Ac 3Ph 520 V (-15%) – 690 V (+10%) - INVT Goodrive 35 Series Operation Manual

Goodrive35 inverters
Note:
1. The rated derate voltage of the input reactor is 2%± 15%.
2. The power factor of the input side is above 90% after installing DC reactor.
3. The rated derate voltage of the output reactor is 1%±15%.
4. Above options are external, the customer should indicate when purchasing.
D.6.2 AC 3PH 520 V (-15%) – 690 V (+10%)
Inverter power
GD35-022-6-C1/D1/H1
GD35-030-6-C1/D1/H1
GD35-037-6-C1/D1/H1
GD35-045-6-C1/D1/H1
GD35-055-6-C1/D1/H1
GD35-075-6-C1/D1/H1
GD35-090-6-C1/D1/H1
GD35-110-6-C1/D1/H1
GD35-132-6-C1/D1/H1
GD35-160-6-C1/D1/H1
GD35-185-6-C1/D1/H1
GD35-200-6-C1/D1/H1
GD35-220-6-C1/D1/H1
GD35-250-6-C1/D1/H1
GD35-280-6-C1/D1/H1
GD35-315-6-C1/D1/H1
GD35-350-6-C1/D1/H1
GD35-400-6-C1/D1/H1
GD35-500-6-C1/D1/H1
GD35-560-6-C1/D1/H1
GD35-630-6-C1/D1/H1
Note:
1. The rated derate voltage of the input reactor is 2%± 15%.
2. The power factor of the input side is above 90% after installing DC reactor.
3. The rated derate voltage of the output reactor is 1%±15%.
4. Above options are external, the customer should indicate when purchasing.
D.7 Filter
For 380 V 110 kW and below models, J10 is not connected by default. If it is necessary to meet the
requirements of C3 level, connect the J10 in the manual bag;
380 V 132 kW and above models can meet C3 requirements, and J10 is connected by default.
Input reactor
ACL2-030G-6
ACL2-030G-6
ACL2-055G-6
ACL2-055G-6
ACL2-055G-6
ACL2-110G-6
ACL2-110G-6
ACL2-110G-6
ACL2-185G-6
ACL2-185G-6
ACL2-185G-6
ACL2-250G-6
ACL2-250G-6
ACL2-250G-6
ACL2-350G-6
ACL2-350G-6
ACL2-350G-6
Standard configuration
Standard configuration
Standard configuration
Standard configuration
266
Appendix D Peripheral options and parts
DC reactor Output reactor
DCL2-030G-6
DCL2-030G-6
DCL2-055G-6
DCL2-055G-6
DCL2-055G-6
DCL2110G-6
DCL2-110G-6
DCL2-110G-6
DCL2-185G-6
DCL2-185G-6
DCL2-185G-6
DCL2-250G-6
DCL2-250G-6
DCL2-250G-6
DCL2-350G-6
DCL2-350G-6
DCL2-350G-6
DCL2-400G-6
DCL2-560G-6
DCL2-560G-6
DCL2-630G-6
OCL2-030G-6
OCL2-030G-6
OCL2-055G-6
OCL2-055G-6
OCL2-055G-6
OCL2-110G-6
OCL2-110G-6
OCL2-110G-6
OCL2-185G-6
OCL2-185G-6
OCL2-185G-6
OCL2-250G-6
OCL2-250G-6
OCL2-250G-6
OCL2-350G-6
OCL2-350G-6
OCL2-350G-6
OCL2-400G-6
OCL2-560G-6
OCL2-560G-6
OCL2-630G-6
