Goodrive35 inverters
LED No. Name
1 Online
2 Offline/Fault

A.3 CANopen optional cards

Refer to the operation manual of EC-TX105 CANopen communication cards.
Color
ON-module online and data can be exchanged.
Green
OFF-module is not in "online" state.
ON-module offline and data can't be exchanged.
OFF-module is not in "offline" state.
1. Flicker frequency 1 Hz-configuration error: The length of user
parameter data sets is different from that of network
configuration process during module initialization process.
2. Flicker frequency 2 Hz-user parameter data error: The length
Red
or content of user parameter data sets is different from that of
network configuration process during module initialization
process.
3. Flicker frequency 4 Hz-PROFIBUS/CANOPEN
communication ASIC initialization error.
4. OFF-Diagnostic closed.
Function
242
Appendix A Extension card
