INVT Goodrive 35 Series Operation Manual page 91

Goodrive35 inverters
Function
Name
code
but one fault
Type of the last
P07.30
but two fault
Type of the last
P07.31
but three fault
Type of the last
P07.32
but four fault
P07.33 Running frequency at present fault
P07.34 Ramp reference frequency at present fault
P07.35 Output voltage at present fault
P07.36 Output current at present fault
P07.37 Bus voltage at present fault
P07.38 Max temperature at present fault
P07.39 Input terminals state at present fault
P07.40 Output terminals state at present fault
P07.41 Running frequency at the last fault
P07.42 Ramp reference frequency at the last fault
P07.43 Output voltage at the last fault
P07.44 Output current at the last fault
P07.45 Bus voltage at the last fault
P07.46 Max temperature at the last fault
P07.47 Input terminals state at the last fault
P07.48 Output terminals state at the last fault
P07.49 Running frequency at the last but two fault
P07.50 Output voltage at at the last but two faults
P07.51 Output current at at the last but two faults
P07.52 Output current at at the last but two fault
P07.53 Bus voltage at previous 2 fault
P07.54 Max temperature at at the last but two fault
Detailed instruction of parameters
26: Panel communication fault (PCE)
27: Parameter uploading fault (UPE)
28: Parameter downloading fault (DNE)
29: PROFIBUS communication fault (E-DP)
30: Ethernet communication fault (E-NET)
31: CANopen communication fault (E-CAN)
32: Grounding short circuit fault 1 (ETH1)
33: Grounding short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment (STu)
36: Undervoltage fault (LL)
37: Encoder offline fault (ENC1O)
38: Encoder reverse fault (ENC1D)
39: Encoder Z pulse offline fault (ENC1Z)
43: Motor overtemperature fault (OT)
84
Function parameters
Default Mod
value ify
●
●
●
●
0.00 Hz
0.00 Hz
0 V
0.0 A
0.0 V
0.0° C
●
0
●
0
●
0.00 Hz
●
0.00 Hz
●
0 V
●
0.0 A
●
0.0 V
●
0.0° C
●
0
●
0
●
0.00 Hz
●
0.00 Hz
●
0 V
●
0.0 A
●
0.0 V
●
0.0° C
