INVT Goodrive 35 Series Operation Manual page 114

Goodrive35 inverters
Function
Name
code
Shift frequency of
P13.04
source current
P13.05 Reserved
Pulse superposing
P13.06
voltage
P13.07 Control parameter 0 0.0 – 400.0%
P13.08 Control parameter 1 0x0000 – 0xFFFF
P13.09 Control parameter 2 0.00 – 655.35
Initial angle
compensation of
P13.10
synchronous
machine
Maladjustment
P13.11
detection time
High frequency
P13.12 compensation
coefficient
Brake current of
P13.13
short-circuit
Brake retention
P13.14 time before
starting
The brake
P13.15 retention time
when stopping
P14 Group Serial communication
Local
P14.00 communication
address
Detailed instruction of parameters
0.0% – 80.0% (max frequency)
0.0 – 300.0% (rated voltage of the motor)
0.0 – 359.9
Adjust the response of anti-maladjustment. Bigger
load inertia may increase the value, but the response
will be slower.
Setting range: 0.0 – 10.0 s
When the motor speed is faster than the rated speed,
the parameter is valid, if vibration occurs to the
motor, please adjust the parameter.
Setting range: 0.0 – 100.0%
When P01.00=0 during the starting of the inverter,
set P13.14 to a non-zero value to enter the short
circuit brake.
When the running frequency is lower than P01.09
during the stopping of the inverter, set 13.15 to a
non-zero value to enter into stopping short circuited
brake and then carry out the DC brake at the time set
by P01.12 (refer to the instruction of P01.09 –
P01.12) .
Setting range of P13.13: 0.0 – 150.0% (the inverter)
Setting range of P13.14: 0.0 – 50.0s
Setting range of P13.15: 0.0 – 50.0s
The setting range: 1 – 247
When the master is writing the frame, the
communication address of the slave is set to 0; the
address is the communication address. All slaves on
the MODBUS fieldbus can receive the frame, but the
107
Function parameters
Default Mod
value ify
○
20.0%
◎
100.0%
○
0.0%
○
0x0000
○
2.00
○
0.0
○
0.5 s
○
0.0%
○
0.0%
○
0.0 s
○
0.0 s
○
1
