INVT Goodrive 35 Series Operation Manual page 76

Goodrive35 inverters
Function
Name
code
voltage
Voltage increasing
P04.29
time
Voltage
P04.30
decreasing time
Maximum output
P04.31
voltage
Minimum output
P04.32
voltage
P05 Group Input terminals
P05.00 HDI input
S1 terminal
P05.01
function
S2 terminal
P05.02
function
S3 terminal
P05.03
function
S4 terminal
P05.04
function
S5 terminal
P05.05
function
S6 terminal
P05.06
function
Detailed instruction of parameters
voltage is set through keypad.
The setting range: 0.0% – 100.0%
Voltage increasing time is the time when the inverter
accelerates from the output minimum voltage to the
output maximum voltage.
Voltage decreasing time is the time when the inverter
decelerates from the output maximum voltage to the
output minimum voltage.
The setting range: 0.0 – 3600.0s
Set the upper and low limit of the output voltage.
The setting range of P04.31: P04.32 – 100.0%
(the rated voltage of the motor)
The setting range of P04.32: 0.0% – P04.31
(the rated voltage of the motor)
0: High pulse input. See P05.49 – P05.54
1: Digital input. See P05.09
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting and A setting
69
Function parameters
Default Mod
value ify
○
5.0 s
○
5.0 s
◎
100.0%
◎
0.0%
◎
0
◎
1
◎
4
◎
7
◎
0
◎
0
◎
0
