Goodrive35 inverters
Function
code
P05.01 S1 terminals function
P05.02 S2 terminals function
P05.03 S3 terminals function
P05.04 S4 terminals function
P05.05 S5 terminals function
P05.06 S6 terminals function
P05.07 S7 terminals function
P05.08 S8 terminals function
P05.09 HDI terminal function
Name
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause (stop at present frequency)
27: Traverse reset (return to the center
frequency)
28: Electronic gear selection
29: Torque control disabling
30: ACC/DEC disabling
31: Pulse ascending
32: Pulse descending
33: Cancel the frequency change setting
temporarily
34: DC brake
Detailed instruction of parameters
165
Basic operation instruction
Default
value
1
4
7
0
0
0
0
0
0
