Goodrive35 inverters
Model
22 kW – 45 kW
55 kW – 132 kW
160 kW – 220 kW
250 kW – 350 kW
Wall installation of 660 V 160-220 kW inverters
Wall installation of 660 V 250-350 kW inverters
Installation dimension (unit: mm)
W1
W2
270
130
325
200
500
180
680
230
Appendix C Dimension drawings
H1
H2
555
540
325
680
661
365
870
850
360
960
926
380
253
D1
Installation hole
7
9.5
11
13
