INVT Goodrive 35 Series Operation Manual page 45

Goodrive35 inverters
No. Name
2 Unit LED
Code
3
displaying
zone
Digital
4 potentiom
eter
5 Buttons
TRIP
Mean the unit displayed currently
5-figure LED display displays various monitoring data and alarm code such as
set frequency and output frequency.
Displayed Correspon
word ding word
0
3
6
9
C
F
L
o
S
v
Tuning frequency. Please refer to P08.41.
Program
ming key
Entry key
UP key
DOWN
key
Right-shif
t key
Description
inverter is in the remote communication control
state.
LED for faults
LED on when the inverter is in the fault state; LED
off in normal state; LED blinking means the inverter
is in the pre-alarm state.
Hz
RPM
A
%
V
Displayed Correspon
word ding word
1
4
7
A
d
H
N
P
t
.
Enter or escape from the first level menu and
remove the parameter quickly
Enter the menu step-by-step
Confirm parameters
Increase data or function code progressively
Decrease data or function code progressively
Move right to select the displaying parameter
circularly in stopping and running mode.
38
Keypad operation procedure
Frequency unit
Rotating speed unit
Current unit
Percentage
Voltage unit
Displayed Correspon
word ding word
2
5
8
B
E
I
n
r
U
-
