Goodrive35 inverters
Function
Average non-fault time 2 years (25° C ambient temperature)
Protective degree

3.4 Name plate

Note: After the CE certification, the icon can be marked.

3.5 Type designation key

Key Sign
①
Abbreviation
②
Rated power
Voltage
③
degree
④
Lot number
IP20
Pollution level Level 2
Cooling Air-cooling
Built-in for inverters of 380 V (≤30 kW)
Brake unit
External for others
380 V models can satisfy IEC61800-3 C3 requirements
EMC filter External filter: optional is optional, but should meet the
requirement of IEC61800-3 C2
Fig 3-4 Name plate
Instruction
Abbreviation Goodrive35: Goodrive35 close-loop vector control inverters
5R5-5.5 kW
Power + Load
G—constant torque load
4: AC 3PH 380 V (-15%) – 440 V (+10%)
Rated voltage: 380 V
Voltage degree
6: AC 3PH 520 V (-15%) – 690 V (+10%)
Rated voltage: 660 V
C1: support 24 V incremental encoder
D1: support rotary transformer
Optional PG cards with functions of pulse and direction
pulse input reference
Lot number H1: support 5 V/12 V incremental encoder,
Pulse + direction pulse input reference
H2: support 5 V incremental encoder for high speed
differential signal processing,
Pulse + direction pulse input reference (specific for
Specification
Content
10
