Goodrive35 inverters
Function
Name
code
Integral ratio of
P08.43 keypad
potentiometer
UP/DOWN
P08.44
terminals control
UP terminals
P08.45 frequency
changing ratio
DOWN terminals
P08.46 frequency
changing ratio
Frequency setting
P08.47
at power loss
Detailed instruction of parameters
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when multi-step speed
has the priority
LED hundreds: action selection during stopping
0: Setting is valid
1: Valid during running, cleared after stopping
2: Valid during running, cleared after receiving the
stop command
LED thousands: ∧/∨ keys and digital
potentiometer integral function
0: The integral function is valid
1: The integral function is invalid
0.01 – 10.00 Hz/s
0x000 – 0x221
LED ones: frequency control selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step are priority, it is invalid to the
multi-step
LED hundreds: action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving the stop
commands
0.01 – 50.00 Hz/s
0.01 – 50.00 Hz/s
0x000 – 0x111
LED ones: Action selection when power off.
90
Function parameters
Default Mod
value ify
○
0.10 Hz/s
○
0x000
○
0.50 Hz/s
○
0.50 Hz/s
○
0x000
