INVT Goodrive 35 Series Operation Manual page 160

Goodrive35 inverters
Up terminal function selection=10
DOWN terminal function
selection=11
Relative parameters list:
Function
code
P00.03 Max output frequency
Upper limit of the running
P00.04
Lower limit of the running
P00.05
P00.06 A frequency command
P00.07 B frequency command
B frequency command
P00.08
Combination of the setting
P00.09
P05.01 –
Multi-function digital input
P05.09
F
Sx
Sy
Name
P00.04 – 400.00 Hz
P00.05 – P00.03
frequency
0.00 Hz – P00.04
frequency
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Simple PLC program setting
6: Multi-step speed running setting
7: PID control setting
8: MODBUS communication setting
9: PROFIBUS/CANopen communication
setting
10: Ethernet communication setting
(reserved)
11: Reserved
0: Maximum output frequency
reference 1: A frequency command
0: A
1: B
2: (A+B) combination
source 3: (A-B) combination
4: Max (A, B) combination
5: Min (A, B) combination
10: Increasing frequency setting (UP)
terminals 11: Decreasing frequency setting (DOWN)
UP terminal frequency increasing integral rate P08.44
DOWNterminal frequency increasing integral rate P08.45
Detailed instruction of parameters
153
Basic operation instruction
T
UP terminal state
T
DOWN terminal state
T
Default
value
50.00 Hz
50.00 Hz
0.00 Hz
0
2
0
0
