INVT Goodrive 35 Series Operation Manual page 75

Goodrive35 inverters
Function
Name
code
V/F voltage 2 of
P04.19
motor 2
V/F frequency 3 of
P04.20
motor 2
V/F voltage 3 of
P04.21
motor 2
V/F slip
P04.22 compensation
gain of motor 2
Vibration control
factor at low
P04.23
frequency of motor
2
Vibration control
factor at high
P04.24
frequency of motor
2
Vibration control
P04.25
threshold of motor 2
Energy-saving
P04.26
operation
P04.27 Voltage setting
P04.28 Keypad setting The function code is the voltage displaying when the
Detailed instruction of parameters
In SVPWM control mode, current fluctuation may
occur to the motor on some frequency, especially the
motor with big power. The motor cannot run stably or
overcurrent may occur. These phenomena can be
canceled by adjusting this parameter.
The setting range of P04.23: 0 – 100
The setting range of P04.24: 0 – 100
The setting range of P04.25: 0.00 Hz – P00.03
(the Max frequency)
0: No operation
1: Automatic energy-saving operation (reserved)
Motors will automatically adjust the output voltage to
save energy when light loads.
Select the output setting channel at V/F curve
separation.
0: Keypad: the output voltage is determined by
P04.28.
1: AI1 ;
2: AI2;
3: AI3;
4: HDI;
5: Multi-step speed;
6: PID;
7: MODBUS communication;
8: PROFIBUS/CANopen communication;
9: Ethernet communication;
10: Reserved
Note: 100% corresponds to the rated motor voltage.
68
Function parameters
Default Mod
value ify
○
0.0%
○
0.00 Hz
○
0.0%
○
100.0%
○
10
○
10
○
30.00 Hz
◎
0
○
0
○
100.0%
