Goodrive35 inverters
Key Sign
The type designation contains information on the inverter. The user can find the type designation on
the type designation label attached to the inverter or the simple name plate.

3.5.1 Model

3.6 Rated values

3.6.1 Rated value of AC 3PH 380 V (-15%) – 440 V (+10%)
Model
GD35-1R5G-4-C1/D1/H1
GD35-2R2G-4-C1/D1/H1
GD35-004G-4-C1/D1/H1/H2/S1
GD35-5R5G-4-C1/D1/H1/H2/S1
GD35-7R5G-4-C1/D1/H1/H2/S1
GD35-011G-4-C1/D1/H1/H2/S1
GD35-015G-4-C1/D1/H1/H2/S1
GD35-018G-4-C1/D1/H1/H2/S1
GD35-022G-4-C1/D1/H1/H2/S1
GD35-030G-4-C1/D1/H1/H2/S1
GD35-037G-4-C1/D1/H1/S1
GD35-045G-4-C1/D1/H1/S1
GD35-055G-4-C1/D1/H1/S1
GD35-075G-4-C1/D1/H1/S1
GD35-090G-4-C1/D1/H1/S1
GD35-110G-4-C1/D1/H1/S1
GD35-132G-4-C1/D1/H1/S1
GD35-160G-4-C1/D1/H1/S1
GD35-185G-4-C1/D1/H1/S1
GD35-200G-4-C1/D1/H1/S1
GD35-220G-4-C1/D1/H1/S1
GD35-250G-4-C1/D1/H1/S1
GD35-280G-4-C1/D1/H1/S1
GD35-315G-4-C1/D1/H1/S1
Instruction
machine tools)
S1: Support sin/cos encoder, sin/cos (1 Vpp) eg
Heidenhain ERN1387; support quadrature pulse input
GD35 – 5R5G – 4 –H1
① ②
Output
power (kW)
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
Content
③ ④
Input current
(A) current (A)
5.0
5.8
13.5
19.5
25
32
40
47
56
70
80
94
128
160
190
225
265
310
345
385
430
460
500
580
11
Product Overview
Carrier
Output
frequency
( kHz)
1 – 15 (8)
3.7
1 – 15 (8)
5
1 – 15 (8)
9.5
1 – 15 (8)
14
1 – 15 (8)
18.5
1 – 1s5 (8)
25
1 – 15 (4)
32
1 – 15 (4)
38
1 – 15 (4)
45
1 – 15 (4)
60
1 – 15 (4)
75
1 – 15 (4)
92
1 – 15 (4)
115
1 – 15 (2)
150
1 – 15 (2)
180
1 – 15 (2)
215
1 – 15 (2)
260
1 – 15 (2)
305
1 – 15 (2)
340
1 – 15 (2)
380
1 – 15 (2)
425
1 – 15 (2)
480
1 – 15 (2)
530
1 – 15 (2)
600
