Goodrive35 inverters
Function
Name
code
B frequency
P00.08 command
reference
Combination of
P00.09
setting source
Detailed instruction of parameters
multi-step speed control) to select the running
frequency, running direction, ACC/DEC time and the
keeping time of corresponding stage. See the
function description of P10 for detailed information.
6: Multi-step speed running setting
The inverter runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the current
running stage, and set P10 to select the current
running frequency.
The multi-step speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can
only be the 1 – 15 stage. The setting stage is 0 – 15 if
P00.06 or P00.07 equals to 6.
7: PID control setting
The running mode of the inverter is process PID
control when P00.06=7 or P00.07=7. It is necessary
to set P09. The running frequency of the inverter is
the value after PID effect. See P09 for the detailed
information of the given source, given value,
feedback source of PID.
8: MODBUS communication setting
The frequency is set by MODBUS communication.
See P14 for detailed information.
9: PROFIBUS/CANopen communication setting
The frequency is set by PROFIBUS/ CANopen
communication. See P15 for the detailed information.
10: Ethernet communication setting (reserved)
See P16 for the detailed information.
11: Reserved
12: Pulse string AB setting
0: Maximum output frequency, 100% of B frequency
setting corresponds to the maximum output
frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust on
the base of A frequency command
0: A, the current frequency setting is A frequency
command
47
Function parameters
Default Mod
value ify
○
0
○
0
