Chapter 2 Quick Start-up

2.1 What this chapter contains

This chapter mainly describes the basic guidelines during the installation and commission procedures
on the inverter, which you may follow to install and commission the inverter quickly.

2.2 Unpacking inspection

Check as followings after receiving products:
1. Check that there are no damage and humidification to the package. If not, please contact with
local agents or company offices.
2. Check the information on the type designation label on the outside of the package to verify
that the drive is of the correct type. If not, please contact with local dealers or company offices.
3. Check that there are no signs of water in the package and no signs of damage or breach to
the inverter. If not, please contact with local dealers or company offices.
4. Check the information on the type designation label on the outside of the package to verify
that the name plate is of the correct type. If not, please contact with local dealers or company
offices.
5. Check to ensure the accessories (including user's manual, control keypad and extension
card) inside the device is complete. If not, please contact with local dealers or company offices.

2.3 Application confirmation

Check the machine before beginning to use the inverter:
1. Check the load type to verify that there is no overload of the inverter during work and check
that whether the drive needs to modify the power degree.
2. Check that the actual current of the motor is less than the rated current of the inverter.
3. Check that the control accuracy of the load is the same of the inverter.
4. Check that the incoming supply voltage is correspondent to the rated voltage of the inverter.
5. Check that the communication needs option card or not.

2.4 Environment

Check as followings before the actual installation and usage:
1. Check that the ambient temperature of the inverter is below 40° C. If exceeds, derate 1% for
every additional 1° C. Additionally, the inverter cannot be used if the ambient temperature is
above 50° C.
Note: for the cabinet inverter, the ambient temperature means the air temperature inside the
cabinet.
2. Check that the ambient temperature of the inverter in actual usage is above -10° C. If not, add
heating facilities.
Note: for the cabinet inverter, the ambient temperature means the air temperature inside the
cabinet.
3. Check that the altitude of the actual usage site is below 1000m. If exceeds, derate 1% for
every additional 100m.
