Goodrive35 inverters
Set value
Switch between A setting
13
and B setting
Switch between A setting
14
and combination setting
Switch between B setting
15
and combination setting
16 Multi-step speed terminal 1 The 16 stage speeds can be set by the combination of
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1 Select 4 ACC/DEC time by the combination of the 2
22 ACC/DEC time selection 2
23 Simple PLC stop reset
24 Simple PLC pause
25 PID control pause
Traverse pause (stop at
26
the current frequency)
Function
internal UP/DOWN of the inverter to make the given
frequency restore to the frequency given by the main
given frequency channel.
This function can realize the shifting between the
frequency setting channels.
The 13
frequency given channel and B frequency given channel.
The 14
frequency given channel and the combination setting
channel set by P00.09
The 15
frequency given channel and the combination setting
channel set by P00.09
digital state of four terminals.
Note: multi-step speed 1 is the LSB; multi-step speed 4 is
the MSB.
Shield the multi-step speed selection terminal function to
keep the setting value at the current state.
terminals.
Restart simple PLC and clear memory state of PLC.
Program pause during PLC implement. Run at the current
speed stage. After cancel the function, simple PLC
continues to run.
Temporal PID invalid and the inverter will output at the
current frequency.
The inverter will stop at the current output and after
canceling the function, the inverter will continue to
traverse run at the current frequency.
Instructions
th
function can realize the shifting between A
th
function can realize the shifting between A
th
function can realize the shifting between B
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Terminal Terminal ACC/DEC time
1 2
OFF OFF ACC/DEC time 1 P00.11/P00.12
ON OFF ACC/DEC time 2 P08.00/P08.01
OFF ON ACC/DEC time 3 P08.02/P08.03
ON ON ACC/DEC time 4 P08.04/P08.05
162
Basic operation instruction
Multi-step Multi-step
speed 2 speed 1
BIT1 BIT0
Corresponding
selection parameter
