Goodrive35 inverters
Function
Auto-adjustment of the
Restart after rotating
Terminal analog input
Terminal switch input
Peripheral
interface
Spindle stopping
Position reference
Frequency division
Speed/position mode
Mountable method
Others
Temperature of the
running environment
voltage
Fault protection
speed tracking
resolution
resolution
Analog input
Analog output
Digital input
Digital output
Relay output
Servo control
output
Encoder
Positioning
communication setting
Switch between the combination and single setting
channel
Keep constant voltage automatically when the grid
voltage transients
Provide more than 30 fault protection functions:
overcurrent, overvoltage, undervoltage, overheating,
phase loss and overload, etc.
Smooth starting of the rotating motor
Note: Only for the inverter≥4 kW
≤ 20 mV
≤ 2 ms
2 (AI1, AI2) 0 – 10 V/0 – 20 mA and 1 (AI3) -10 – 10 V
2 (AO1, AO2) 0 – 10 V/0 – 20 mA
8 common inputs, the Max frequency: 1 kHz, internal
impedance: 3.3 kΩ;
1 high speed input, the Max frequency: 50 kHz
1 high speed pulse output, the Max frequency: 50 kHz;
1 Y terminal open collector output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3 A/AC 250 V,1 A/DC 30 V
For spindle positioning and control sequence
Internal 7 scale marks and 4 zero marks
External zero-position detection switch positioning
Encoder Z phase positioning
Pulse train reference: position control
Encoder frequency division output
(H1 and H2 inverters)
Terminal shifting
C1 support 100 kHz, D1 support 500 kHz, H1 support
300 kHz and H2 support 400 kHz
Z pulse and photoelectric switch positioning
Wall, flange and floor mountable
-10 – 50° C, if temperature is above 40° C, derate 1% for
every additional 1° C.
9
