INVT Goodrive 35 Series Operation Manual page 148

Goodrive35 inverters
Function
code
Keypad setting torque -300.0% – 300.0% (rated current of the motor)
P03.12
Torque reference filter
P03.13
Upper frequency of
P03.14 forward rotation in
vector control
Upper frequency of
P03.15 reverse rotation in
vector control
Keypad setting for
P03.16 upper frequency of
forward rotation
Keypad setting for
P03.17 upper frequency of
reverse rotation
Upper electromotion
P03.18
torque source
Upper brake torque
P03.19
Name
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: MODBUS communication setting torque
8: PROFIBUS/CANopen communication
setting torque
9: Ethernet communication setting torque
10: Reserved
0.000 – 10.000 s
time
0: Keypad (P03.16 sets P03.14,P03.17 sets
P03.15)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI
5: Multi-step
6: MODBUS communication setting upper-limit
frequency
7: PROFIBUS/CANopen communication
8: Ethernet communication
9: Reserved
0.00 Hz – P00.03 (max frequency)
0.00 Hz – P00.03 (max frequency)
0: Keypad (P03.20 sets P03.18, P03.21 sets
P03.19)
1: AI1 (100% relative to three times of rated
motor current)
2: AI2 (same as above)
3: AI3 (same as above)
source
4: HDI (same as above)
5: MODBUS communication (same as above)
Detailed instruction of parameters
141
Basic operation instruction
Default
value
10.0%
0.100s
0
0
50.00 Hz
50.00 Hz
0
0
