Goodrive35 inverters
Function
code
P08.00
P08.01
P08.02
P08.03
P08.04
P08.05
P08.28
Interval time of automatic fault
P08.29

7.8 Frequency setting

Goodrive35 series inverters can set the frequency by various means. The given channel can be
divided into main given channel and assistant given channel.
There are two main given channels: A frequency given channel and B frequency given channel.
These two given channels can carry out mutual simple math calculation between each other. And the
given channels can be shifted dynamically through set multi-function terminals.
There are three assistant given channels: keypad UP/DOWN input, terminals UP/DOWN switch input
and digital potentiometer input. The three ways equal to the effect of input UP/DOWN given in internal
assistant given of the inverter. The user can enable the given method and the effect of the method to
the frequency given by setting function codes.
The actual given of the inverter is consisted of main given channel and assistant given channel.
Name
ACC time 2
DEC time 2
ACC time 3
DEC time 3
ACC time 4
DEC time 4
Fault reset times
reset
Detailed instruction of parameters
0.0 – 3600.0 s
0.0 – 3600.0 s
0.0 – 3600.0 s
0.0 – 3600.0 s
0.0 – 3600.0 s
0.0 – 3600.0 s
0 – 10
0.1 – 3200.0 s
151
Basic operation instruction
Default
value
Depend on
model
Depend on
model
Depend on
model
Depend on
model
Depend on
model
Depend on
model
0
1.0 s
