10.4

Speed Sensor 1

The frequency inverters are to be adapted to the application depending on the re-
quirements. A part of the available
ment of the actual speed for the control functions and methods. The necessary con-
nection of an incremental speed sensor is done on the digital control terminals S5IND
(track A) and S4IND (track B) of the frequency inverter.
With expansion modules EM and sensor input modules, it is also possible to connect
and evaluate sensors as speed sensor 2. Please refer to the corresponding operating
instructions. Speed sensor 1 and speed sensor 2 are configured independently from
one another.

10.4.1 Operation Mode Speed Sensor 1

Operation mode
incremental speed sensor. Connect an unipolar speed sensor to the standard control
terminals.
Operation mode
0 - Off
1 – Single evaluation
4 –
11 –
12 –
31 –
32 –
101 –
104 –
111 –
112 –
131 –
132 –
128
490 for speed sensor 1 can be selected according to the connected
490
Speed measurement is not active; the digital inputs are
available for other functions.
Two-channel speed sensor with recognition of direction
of rotation via track signals A and B; one signal edge is
evaluated per division mark.
Two-channel speed sensor with recognition of direction
Quadruple evalua-
of rotation via track signals A and B; four signal edges
tion
are evaluated per division mark.
One-channel speed sensor via track signal A; the actual
Single evaluation speed value is positive. One signal edge is evaluated per
without sign division mark. The digital input S4IND is available for
further functions.
One-channel speed sensor via track signal A; the actual
Double evaluation speed value is positive. Two signal edges are evaluated
without sign per division mark. The digital input S4IND is available
for further functions.
One-channel speed sensor via track signal A. The actual
Single evaluation,
speed value is positive for signal "Low" and negative for
sense of rot. via
signal "High" at digital input S4IND. One signal edge is
contact
evaluated per division mark.
One-channel speed sensor via track signal A. The actual
Double evaluation,
speed value is positive for signal "Low" and negative for
sense of rot. via
signal "High" at digital input S4IND. Two signal edges
contact
are evaluated per division mark.
Single evaluation Same as in operation mode 1. The actual speed value is
inverted inverted. (Alternative to exchanging the track signals)
Quadruple evalua- Same as in operation mode 4. The actual speed value is
tion inverted inverted. (Alternative to exchanging the track signals)
Single evaluation Same as operation mode 11. The actual speed value is
negative negative.
Double evaluation Same as operation mode 12. The actual speed value is
negative negative.
One-channel speed sensor via track signal A. The actual
Single evaluation,
speed value is negative for signal "Low" and positive for
sense of rot. via
signal "High" at digital input S4IND. One signal edge is
contact inverted
evaluated per division mark.
One-channel speed sensor via track signal A. The actual
Double evaluation,
speed value is negative for signal "Low" and positive for
sense of rot. via
signal "High" at digital input S4IND. Two signal edges
contact inverted
are evaluated per division mark.
