If the output current has already been reduced due to the fact that the long-term
overload has used up, the short-term overload is no longer available even if it has not
been used up beforehand. The defined overload reserve (Ixt) of the frequency in-
verter is available again after a power reduction lasting 10 minutes.
Output signals
Digital outputs can signalize the achievement of a limit value – selected in
573.
Mode
15 - Warning Current Limitation
Controller Current Limit.
16 -
Long Term Ixt
Controller Current Limit.
17 -
Short Term Ixt
18 - Controller Current Limit. Tc
Controller Current Limit.
19 -
Motor Temp.
17.2

Voltage controller

The voltage controller contains the functions necessary for monitoring the DC link
voltage.
The DC link voltage which rises in generator operation or in the braking process
−
of the 3-phase machine is controlled to the set limit value by the voltage control-
ler.
The power failure regulation uses the rotation energy of the drive to bridge short-
−
term power failures.
The voltage controller is set with the parameter
with the application.
Operation Mode
0 - Off
1 - Udc-Limitation active
2 - Mains Support active
Udc-Limit. & Mains
3 -
Supp. active
Mains Support active,
12 -
Chopper not active
Udc-Limit. & Mains
13 - Supp. active, Chopper
not active
The function motor chopper is available in the field-oriented control methods (in con-
figurations 210, 230, 410, 411 and 430).
Operating Instructions ACU
06/13
Intelligent Current Limits active. Output current
is limited.
The overload reserve for 60 s has been used up
and the output current is being limited.
The overload reserve for 1 s has been used up
and the output current is being limited.
Intelligent Current Limits active. Maximum heat
sink temperature Tc reached.
Intelligent Current Limits active. Maximum mo-
tor temperature reached.
670
The function is switched off. Brake and Motor chopper
are active and switch with the parameterized thresh-
olds of P506 and P507.
DC link limitation active. Overvoltage controller
switched on, the Brake and Motor chopper are active
and switch with the parameterized thresholds of P506
and P507. Factory setting.
Power failure regulation switched on. Brake and Motor
chopper are active and switch with the parameterized
thresholds of P506 and P507. Suitable for quick shut-
down.
Overvoltage controller and power failure regulation
switched on, with motor chopper.
Power failure regulation switched on. During the
Mains Support, motor and brake chopper are deac-
tivated. In all other cases motor and brake chopper
are active and switch with the parameterized thresh-
olds of P506 and P507.
Overvoltage controller and power failure regulation
switched on. During the Mains Support, motor and
brake chopper are deactivated. In all other cases
motor and brake chopper are active and switch with
the parameterized thresholds of P506 and P507.
670 in accordance
Operation Mode
Function
Operation
211
