Activation via communication module CM
Activation of the control unit through a communication connection is possible only if
the frequency inverter is fitted with an optional communication module CM, and com-
munication takes place via this module. The control unit must be connected to the
frequency inverter.
Establish connection to frequency inverter.
•
• Start communication and select parameter
cation interface.
• Via the communication interface enter value 111 in parameter
34 and confirm this value.
Via the communication interface enter value 123 in parameter
•
34 and confirm this value.
The frequency inverter is re-initialized. The display of the control unit reads "rE-
SEt". After that, the unit is initialized.

7.6.2 Data transfer

In order to transmit a file from the control unit to the frequency inverter, proceed as
follows:
Connect control unit KP 500 to the frequency inverter.
•
After initialization, the data sources available for transmission are displayed.
Use the arrow keys to select the data source (Src. Fy) for the transmission to the
•
frequency inverter.
The files stored in the control unit are available as data sources.
The files stored in the control unit contain all information and parameters stored ac-
cording to the selected copy function ALL or Act (see Chapter "Copy Menu") in the
control unit.
Confirm your selection by pressing the ENT key.
•
The copy process is started. While the copy operation is in process, COPY and,
as a progress indicator the number of the currently processed parameter will be
displayed.
As soon as the copy operation is complete, the control unit will be re-initialized.
