14.6

Fixed reference values

The fixed reference values are to be parameterized as fixed frequencies or fixed per-
centages according to the configuration and function.
The signs of the fixed reference values determine the direction of rotation. A positive
sign means a clockwise rotation; a negative sign means an anticlockwise rotation.
The direction can only be changed via the sign if the
475 or
source
mode with sign (+/-). The direction of rotation can also be stated with the digital
signal sources assigned to the parameters
clockwise
The fixed reference values are to be parameterized in four data sets and are assigned
to further sources via the reference value channel. The use of the functions
change-over 1
fixed reference values.

14.6.1 Fixed Frequencies

The four fixed frequencies define reference values which are selected via the
frequency change-over 1
frequency source
frequency channel.
No. Description
480 Fixed frequency 1
481 Fixed frequency 2
482 Fixed frequency 3
483 Fixed frequency 4
By combining the logic states of the fixed frequency change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed frequency
change-over 1
0
1
1
0
0 = contact open
If an optional expansion module with digital inputs is installed additional fixed fre-
quencies can be selected. In this case refer to the instruction manual of the expansion
module.
Operating Instructions ACU
06/13
Reference percentage source
69.
70 and
Data set change-over 2
66 and
Fixed frequency change-over 2
475 defines the addition of the various sources in the reference
Parameter
Selection of fixed frequencies
Fixed frequency
66
r
change-ove 2
0
0
1
1
1 = contact closed
476 is parameterized to an operation
Start clockwise
71 thus enables the setting of 16
Settings
Min. Max.
-999.99 Hz 999.99 Hz
-999.99 Hz 999.99 Hz
-999.99 Hz 999.99 Hz
-999.99 Hz 999.99 Hz
Function / active fixed value
67
Fixed frequency 1
Fixed frequency 2
Fixed frequency 3
Fixed frequency 4
Reference frequency
68 and
Start anti-
Data set
Fixed
67. The
Reference
Fact. sett.
0.00 Hz
10.00 Hz
25.00 Hz
50.00 Hz
480
481
482
483
161
