14.5

Reference percentage channel

The reference percentage channel combines various signal sources for definition of
the reference figures. The percentage scaling facilitates integration into the applica-
tion, taking various process parameters into account.
The
Reference Percentage Source
available reference value sources depending on the hardware installed.
Reference Percentage Source
Abs. value analog value
1 -
MFI1A
2 - Abs. Analog Value EM-S1INA
Abs. Value MFI1A + EM-
4 -
S1INA
Abs. value fixed percentage
10 -
value (FP)
11 - Abs. value MFI1A + FP
12 - Abs. Value EM-S1INA + FP
Abs. Value MFI1A + EM-
14 -
S1INA + FP
20 - Abs. value Motorpoti (MP)
21 - Abs. value MFI1A + MP
22 - Abs. Value EM-S1INA + MP
Abs. Value MFI1A + EM-
24 -
S1INA + MP
Abs. Val. Rep. Freq./PWM
32 -
Input (F3)
33 - Abs. value MFI1A + F3
Abs. value MFI1A + FP + MP
90 -
+ F3 (+ EM-S1INA)
Abs. Value Obj 0x6071 Target
95 -
Torque
Abs. Value Profibus OUT-
96 -
PZD3
Abs. Val. FT-Output Percent-
99 -
age 1
101 to 199
1)
The reference value source is only available if an optional expansion module with
analog input is connected. For information, refer to the expansion module operating
instructions.
158
476 determines the additive assignment of the
476
1)
1)
1)
1)
1)
1)
1)
Operating Instructions ACU
Function
Reference value source is the multifunctional in-
put 1 in analog
Operation mode
Reference value source is the Analog value of
EM-S1INA.
Combination of the operation modes 1 and 2.
The percentage according to
75,
change-over 1 Fixed percent change-
76 and the current data set.
over 2
Combination of the operation modes 1 and 10.
Combination of the operation modes 2 and 10.
Combination of the operation modes 1, 2 and
10.
Reference value source is the function
72 and
Motorpoti Up Percent Motorpoti
73.
Down
Combination of the operation modes 1 and 20.
Combination of the operation modes 2 and 20.
Combination of the operation modes 1,2 and
20.
The frequency signal on the digital input ac-
cording to
Operation mode
repetition frequency input.
Combination of the operation modes 1 and 32.
Combination of the operation modes 1, 10, 20,
32(+ analog input of an expansion module).
Reference value source is CANopen Object
0x6071.
Reference value source is Profibus OUT-PZD3.
Reference value source is the output of the
function table FT-Output percentage 1.
Operation modes with signs (+/-).
452.
Fixed percent
Percent
496 for the PWM-/
1)
