15.2.2 Frequency Output MFO1F

The multifunctional output MFO1 can be used as a frequency output in the setting of
Operation Mode
signed to the abs. value of the speed or frequency via the parameter
Freq. Operation
sion modules installed as an option.
Repetition Freq. Operation
0 - Off
1 - Actual Frequency
2 - Stator Frequency
3 - Frequency Speed Sensor 1
5 - Repetition Frequency Input

15.2.2.1 Scaling

The repetition frequency mode for the multifunction output corresponds to the map-
ping of an incremental sensor. The parameter
terized according to the frequency to be output. The minimum frequency of the repe-
tition frequency operation is 30 Hz. Lower values are set as 0 Hz.
The pulse pause relation is not 1:1. The repetition frequency output should be evalu-
ated therefore only with rising or falling edge in the evaluating device.
No.
556 Division Marks
The frequency limit of f
parameter
Operating Instructions ACU
06/13
550 = "3 - Repetition Frequency". The DC 24V output signal is as-
555. The selection of the operation modes depends on the expan-
555
Parameter
Description
=150 kHz may not be exceeded in the calculation of the
max
556.
Division marks
S
max
Function
Repetition frequency operation MFO1 switched off
Abs. value of the
Actual frequency
Abs. value of the
Stator frequency
Abs. value of the
Encoder 1 Frequency
Abs. value of the
Repetition freq. input
Division marks
Settings
Min.
30
150000 Hz
=
Frequency value
Repetition
241.
210.
217.
252.
556 must be parame-
Max. Fact. sett.
8192 1024
