No.
310 Last error
311 Last error but one
312 Error 3
313 Error 4
314 Error 5
315 Error 6
316 Error 7
317 Error 8
318 Error 9
319 Error 10
320 Error 11
321 Error 12
322 Error 13
323 Error 14
324 Error 15
325 Error 16
330 DC –Link Voltage
331 Output voltage
332 Stator frequency
333 Encoder 1 Frequency
335 Phase current Ia
336 Phase current Ib
337 Phase current Ic
338 R.m.s current
339 Isd / reactive current
340 Isq / active current
341 Rotor magnetizing current
342 Torque
343 Analog input MFI1A
346 Analog output MFO1A
349 Repetition frequency output
350 Status of digital inputs
351 Status of digital outputs
352 Time since release
353 Heat sink temperature
354 Inside temperature
355 Controller Status
356 Warning Status
357 Int. value 1
358 Int. value 2
359 Long value 1
360 Long value 2
361 Checksum
362 No. of errors
363 No. of self acknowledged errors
Operating Instructions ACU
06/13
Error List
Description
Error List
Error Environment
Error List
Unit Display range
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
h:m; F 00000:00; FXXXX
V 0.0 ... U
dmax
V 0.0 ... U
FUN
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
Nm ± 9999.9
% ± 100.00
V 0.0 ... 24.0
Hz 0.00 ... 999.99
- 00 ... 255
- 00 ... 255
00000:00:00.000
h:m:s.ms
deg.C 0 ... T
kmax
deg.C 0 ... T
imax
- C0000 ... CFFFF
- A0000 ... AFFFF
- ± 32768
- ± 32768
- ± 2147483647
- ± 2147483647
- OK / NOK
- 0 ... 32767
- 0 ... 32767
Chapter
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
21.2
21.2
20.2
20.2
20.2
21.3
21.4
20.2
20.2
20.2
20.2
20.2
20.1
20.1
