ACU 401 (18.5 to 30.0 kW)

Frequency inverter
A
Terminal strip X10 (Phoenix ZEC 1.5/3ST5.0)
B
Plug-in terminals for the relay output
Standard fittings with fitting screws (M4x20, M4x70)
C
for vertical assembly
Brief Instructions and Operating Instructions on CD ROM
D
Control terminals X210A / X210B (Wieland DST85 / RM3.5)
E
Plug-in terminal for connection of the control signals
Please check incoming goods for quality, quantity and nature without delay. Obvious
defects such as exterior damage of the packing and/or the unit must be notified to the
sender within seven days for insurance reasons.
